TieDex UK LG 55UL3J-M UL3J Series – 55″ with Integrated Pro:Idiom LED-backlit LCD display – 4K – for digital signage
LG 55UL3J-M – 55″ Diagonal Class UL3J Series LED-backlit LCD display – digital signage with Integrated Pro:Idiom – webOS – 4K UHD (2160p) 3840 x 2160 – Direct LED – ash blue
Basic Specifications
- Manufacturer’s Part Number
- 55UL3J-M.AEK
- EAN
- 8806084391827
- Product Type
- LED-backlit LCD flat panel display with Integrated Pro:Idiom
- Product Description
- LG 55UL3J-M UL3J Series – 55″ with Integrated Pro:Idiom LED-backlit LCD display – 4K – for digital signage
- HDMI Ports Qty
- 3 ports
- LCD Backlight Technology
- Direct LED
- Resolution
- 3840 x 2160
- Image Aspect Ratio
- 16:9
- Power Consumption Operational
- 105 Watt
- Model
- LG 55UL3J-M
- Dimensions (WxDxH) – without stand
- 123.5 cm x 5.75 cm x 71.5 cm
- Display Format
- 4K UHD (2160p)
- Energy Class
- Class G
- USB
- 2 ports
- Diagonal Class
- 55″
- Video Interface
- HDMI
- Commercial Use
- Digital signage
- Environmental Standards
- ENERGY STAR Qualified, EPEAT Bronze
- Voltage
- AC 100-240 V (50/60 Hz)
- Technology
- ADS
- Colour
- Ash blue
- TV Tuner
- No tuner
- Weight
- 14 kg
- Display Resolution
- 4K Ultra HD (2160p)
- Connectivity
- Wi-Fi, LAN
- Platform
- webOS
- Picture Enhancements
- DCI 80% Colour Gamut
- Storage Capacity
- 16GB eMMC
- Commercial Features
- SNMP support, No Signal image, Sync Mode, Integrated Contents Management System (CMS), SuperSign CMS compatible, SuperSign Control+ compatible, Real Time Communication (webRTC), Local Key Operation, FailOver, SuperSign WB compatible, LG ConnectedCare, LG One:Quick Share compatible, Video Tag, booting logo image, Auto Set ID, play via URL, ISM Method
- Settings Cloning Capability
- Yes
- Included Accessories
- Remote control, cable holder
- Power Consumption Stand by
- 0.5 Watt
- Frame Rate & Enhancement Technology
- 60 Hz Refresh Rate
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 – 80%
Remote Control
- Type
- Remote control
- Battery Included
- Yes
- Battery Included Qty
- 2
- Battery Required Qty
- 2
Audio System
- Features
- Built-in speaker
Stands & Mounts
- Flat Panel Mount Interface
- 300 x 300 mm
- VESA Compatibility
- Yes
Media Player
- USB Port
- Yes
- USB Ports Qty
- 2
- Configuration
- 16GB eMMC
Connections
- Connector Type
- 3 x HDMI input ¦ 2 x USB 2.0 ¦ Audio output ¦ RS-232C input ¦ RS-232C output ¦ LAN
Display
- LCD Display Technology
- ADS
- Resolution
- 3840 x 2160
- Display Format
- 4K UHD (2160p)
- Image Aspect Ratio
- 16:9
- Frame Rate & Enhancement Technology
- 60 Hz Refresh Rate
- LCD Backlight Technology
- Direct LED
- Coating
- 1% haze
- Image Contrast Ratio
- 1200:1
- Dynamic Contrast Ratio
- 1000000:1
- Brightness
- 400 cd/m²
- Viewing Angle
- 178 degrees
- Viewing Angle (Vertical)
- 178 degrees
- Response Time
- 8 ms
- Backlight Life
- 30,000 hour(s)
- Commercial Features
- SNMP support, No Signal image, Sync Mode, Integrated Contents Management System (CMS), SuperSign CMS compatible, SuperSign Control+ compatible, Real Time Communication (webRTC), Local Key Operation, FailOver, SuperSign WB compatible, LG ConnectedCare, LG One:Quick Share compatible, Video Tag, booting logo image, Auto Set ID, play via URL, ISM Method
- Settings Cloning Capability
- Yes
- Operation Hours / Days
- 16 / 7
- Features
- Crestron Connected Compatible, BEACON technology, wireless access point, Cisco Certified, 1.07 billion colours (8-bit+FRC)
General
- Product Type
- LED-backlit LCD flat panel display with Integrated Pro:Idiom
- Energy Class
- Class G
- Power Consumption (Max)
- 160 Watt
- Power Consumption Operational
- 105 Watt
- Power Consumption SDR (On mode)
- 102 kWh/1000h
- Diagonal Class
- 55″
- Commercial Use
- Yes – digital signage
- Series
- UL3J Series
- Platform
- webOS
- Operating System
- webOS 6.0
- TV Tuner
- No tuner
- TV Tuner Presence
- No
- Sensors
- Temperature sensor, brightness sensor
- Video Interface
- HDMI
- HDMI Ports Qty
- 3 ports
- Modes
- Portrait mode, landscape mode, Tile Mode, PM mode
- Picture Enhancements
- DCI 80% Colour Gamut
- Design
- Slim Design
- Dimensions
- Without stand
- Width
- 123.5 cm
- Depth
- 5.75 cm
- Height
- 71.5 cm
- Weight
- 14 kg
- Enclosure Colour
- Ash blue
Miscellaneous
- Included Accessories
- Cable holder
- Compliant Standards
- Plug and Play, FCC Class A certified, CB, EMC, ERP, NRTL, HDCP 2.2, HDCP 1.4
Power
- Power Device
- Power supply
- Input Voltage
- AC 100-240 V (50/60 Hz)
- Power Consumption Stand by
- 0.5 Watt
- Power Consumption (Off Mode)
- 0.5 Watt
- Heat Generation Details
- Cabinet – typical – 358 BTU/h ¦ Cabinet – max – 546 BTU/h
- Features
- Smart energy saving, WOL (Wake on LAN)
Dimensions & Weight (Shipping)
- Width (Shipping)
- 136 cm
- Depth (Shipping)
- 16.2 cm
- Height (Shipping)
- 81 cm
- Weight (Shipping)
- 18.8 kg
Network & Internet Multimedia
- Connectivity
- Wi-Fi, LAN
- LAN Protocol
- Ethernet
- Connect & Share
- Screen Share
Sustainability Information
- EPEAT Compliant
- EPEAT Bronze
- ENERGY STAR Certified
- Yes
