Subframe Cradle and 800kg Transmission Jack Combo
Sealey SFC800COMBO Subframe Cradle and 800kg Transmission Jack
The Sealey SFC800COMBO combines an 800kg capacity transmission jack with a subframe cradle adaptor, creating a versatile workshop solution. This package handles both transmission replacements and subframe removals with adjustable height from 960mm to 1920mm. Multi-angle tilt functionality allows precise positioning during complex automotive repairs.
Heavy-Duty Performance Solutions
Dual-Purpose Functionality
Combines both transmission jack and subframe cradle capabilities in one unit, reducing equipment costs and workshop space requirements.
High Load Capacity
Supports 800kg in transmission jack mode and 450kg as a subframe cradle, handling components from small cars to larger commercial vehicles.
Multi-Angle Positioning
Adjusts 15° forward and 40° backward, allowing technicians to match exact installation angles for complex drivetrain components.
960mm Height Range
Extends from 960mm to 1920mm, accommodating various vehicle lift heights and working positions for technicians of different statures.
Telescopic Vertical Action
Provides smooth height adjustment with two ram extensions, allowing fine control when aligning heavy components.
Stable Work Platform
Built on a 1046 x 1046mm base that maintains stability when handling off-center loads, preventing tipping during critical operations.
Adjustable Saddle Configuration
Allows customisation to match specific vehicle subframe and transmission mounting points, improving fit and reducing installation time.
Technical Information
Sealey SFC800COMBO package includes the 800TTJ 0.8 tonne vertical telescopic transmission jack and the SFC01 subframe/engine load adaptor. 960-1920mm height range with 15° forward/40° backward tilt adjustment. Built on a 1046 x 1046mm base with 110kg total weight. Features two ram extensions with an adjustable saddle configuration.
Package Contents
800TTJ – 0.8 Tonne Vertical Telescopic Transmission Jack
SFC01 – Subframe/Engine Load Adaptor for TTJ Transmission Jacks
