StarTech.com Monitor Desk Mount For 27in 16:9 or 30in 21:9 Ultrawide Screens, VESA 75×75/100×100, Tool-Less Arm Adjustments, C-Clamp/Grommet, Spring-Assisted Arm
- DESK MOUNT MONITOR ARM: Single monitor VESA mount (75×75/100x100mm) supports up to 19.8lb (9kg) 27-inch 16:9 or 30-inch 21:9 ultrawide displays; High-quality mechanical spring tested to 10,000 cycle
- QUICK AND TOOLLESS ASSEMBLY: Premium monitor arm with toolless slide & click design, featuring thumb screws, makes assembly quick and simple; Pre-assembled desk clamp & pole can be easily secured by hand to the desk, saving total installation time
- RANGE OF MOTION: Ergonomic articulating arm with toolless adjustments of +/-180° horizontal swivel, 105° tilt, 240° pan, and 360° screen rotation for portrait & landscape orientations; TAA-compliant
- MOUNTING OPTIONS: Interchangeable desk C-clamp or grommet mount for desks up to 4.3-inches (110mm) thick; Monitor stand includes tools to adjust the arm tension to match the monitor weight; Detachable VESA plates w/quick release mechanism
- ORGANIZED WORKSPACE: Computer monitor mount with cable management channels along the arm to keep cables out of sight; A cable clip on the pole helps maintain a tidy setup
Single monitor desk mount with support up to 30″ monitors and height-adjustable articulating arm
This monitor desk mount is designed to support up to 27-inch 16:9 or 30-inch 21:9 display, creating an ergonomic area for productivity. The mechanical spring-assisted arm enables multiple adjustment to suit different ergonomic needs.
Height Adjustment with One Smooth Motion
The spring arm enables toolless height adjustment of up to 10.6in (270mm) with effortless one-touch motion. Adjust the height of the arm along the 10.2in (261mm) pole. The arm can extend up to 22.2in (590mm) from the pole.
Toolless Assembly
The quick toolless slide and click design makes assembly quick and simple. The pre-assembled desk clamp and pole can be easily secured by hand to the desk, saving total installation time.
Range of Motion
The articulating arm enables toolless adjustments of +/-180° horizontal swivel, 105° tilt, 240° pan, and 360° screen rotation on the VESA plate for portrait or landscape orientations. This flexibility enables users to customize the screen placement for maximum productivity and comfort.
Durable Construction
With its steel and aluminum construction, the premium monitor arm supports a weight capacity of 19.8 lb. (9 kg). Die-cast aluminum arms with mechanical springs that passed 10,000 cycle test and are backed for 10 years for long-lasting performance.
Cable Management
To maintain an organized workspace, the adjustable arm features a cable management channel along the underside to keep cables out of sight, reducing clutter and contributing to a tidy setup. A cable clip on the pole also helps maintain an organized workspace.
The StarTech.com Advantage
| Mounting | |
|---|---|
| Grommet mount desk thickness (max) | 6 cm |
| Clamp mount desk thickness (max) | 11 cm |
| Desk thickness (min) | 1 cm |
| Extension arm (max) | 59 cm |
| Number of displays supported | 1 |
| Maximum VESA mount | 100 x 100 mm |
| Minimum VESA mount | 75 x 75 mm |
| Mounting | Clamp/Grommet |
| Mounting type | Desk |
| Maximum screen size | 76.2 cm (30″) |
| Minimum screen size | 43.2 cm (17″) |
| Maximum weight capacity | 9 kg |
| Ergonomics | |
|---|---|
| Cable management | Yes |
| Pivot angle | -180 – 180° |
| Angle of rotation | 90° |
| Rotating | Yes |
| Swivel angle | 120° |
| Swivelling | Yes |
| Tilt angle range | -15 – 90° |
| Height adjustment range | 270 – 302 mm |
| Height adjustment | Yes |
| Design | |
|---|---|
| Anti-theft function | No |
| Housing material | Aluminium, Plastic, Steel |
| Product colour | Black, Silver |
| Weight & dimensions | |
|---|---|
| Weight | 3 kg |
| Height | 361 mm |
| Depth | 103 mm |
| Width | 674 mm |
| Packaging data | |
|---|---|
| Package weight | 3.8 kg |
| Package height | 462 mm |
| Package depth | 136 mm |
| Package width | 290 mm |
| Packaging content | |
|---|---|
| Manual | Yes |
| Number of screws | 4 |
| Screws included | Yes |
| Number of cable clips | 1 |
| VESA mount included | Yes |
| Wrench type | Hexagonal wrench |
| Wrench included | Yes |
| Other features | |
|---|---|
| Compliance certificates | Trade Agreements Act (TAA) |
| Logistics data | |
|---|---|
| Products per master (outer) case | 5 pc(s) |
| Master (outer) case height | 312 mm |
| Master (outer) case length | 136 mm |
| Master (outer) case width | 706 mm |
