Mellanox Technologies MQM8700-HS2F network switch Managed Gigabit Ethernet (10/100/1000) 1U Black
- Managed IPv6
- Configuring Location Settings (CLI)
- Basic switching RJ-45 Ethernet ports quantity: 1 Console port: RS-232
- 10G support
- 1U Rack mounting
40-port Non-blocking Managed HDR 200Gb/s InfiniBand Smart Switch
Faster servers, combined with high-performance storage and applications that use increasingly complex computations are causing data bandwidth requirements to spiral upward. As servers are deployed with next generation processors, High-Performance Computing (HPC) environments and Enterprise Data Centers (EDC) will need every last bit of bandwidth delivered with Mellanox’s next generation of HDR InfiniBand, high-speed, smart switches. Built with Mellanox’s Quantum InfiniBand switch device, the QM8700 provides up to forty 200Gb/s ports, with full bi-directional bandwidth per port. These stand-alone switches are an ideal choice for top-of-rack leaf connectivity or for building small to extremely large sized clusters. QM8700 is the world’s smartest network switch, designed to enable in-network computing through the Co-Design Scalable Hierarchical Aggregation and Reduction Protocol (SHARP) technology. The Co-Design architecture enables the usage of all active data center devices to accelerate the communications frameworks using embedded hardware, resulting in an order of magnitude application performance improvements.
| Management features |
| Configuring Location Settings (CLI) |
Yes |
| Switch type |
Managed |
| Ports & interfaces |
| USB 2.0 ports quantity |
1 |
| Console port |
RS-232 |
| Fiber optic connector |
QSFP56 |
| Fiber ports quantity |
40 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
1 |
| Network |
| Port mirroring |
Yes |
| 10G support |
Yes |
| Security |
| Security algorithms |
SNMP, SNMPv2, SNMPv3 |
| Protocols |
| Management protocols |
IPv6 |
| Design |
| LED indicators |
Activity, Link |
| Product colour |
Black |
| Form factor |
1U |
| Rack mounting |
Yes |
| Power |
| Input current |
4.5 A |
| AC input frequency |
50 – 60 Hz |
| AC input voltage |
100 – 240 V |
| Operational conditions |
| Operating altitude |
0 – 3200 m |
| Storage relative humidity (H-H) |
10 – 90% |
| Operating relative humidity (H-H) |
10 – 85% |
| Storage temperature (T-T) |
-40 – 70 °C |
| Operating temperature (T-T) |
0 – 40 °C |
| Certificates |
| Certification |
CB, cTUVus, CE, CU, FCC, VCCI, ICES, RCM, RoHS |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
