Lenovo ThinkSystem ST650 V3 server Tower Intel® Xeon® Gold 6438Y+ 2 GHz 64 GB DDR5-SDRAM 1100 W
- No OS
- Intel Xeon Gold 6438Y+ (60MB Cache, 2GHz)
- 64GB DDR5-SDRAM
The Lenovo ThinkSystem ST650 V3 is an ideal 2-socket 4U tower server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The ST650 V3 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.
This product guide provides essential pre-sales information to understand the ThinkSystem ST650 V3 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the ST650 V3 and consider its use in IT solutions.
| Processor | |
|---|---|
| Bus type | OPI |
| Configurable TDP-down | 4.5 W |
| Number of processors installed | 1 |
| Processor cache | 60 MB |
| Processor cores | 32 |
| Processor boost frequency | 4 GHz |
| Processor frequency | 2 GHz |
| Processor model | 6438Y+ |
| Processor family | Intel® Xeon® Gold |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| Maximum internal memory | 4 TB |
| ECC | Yes |
| Internal memory type | DDR5-SDRAM |
| Internal memory | 64 GB |
| Storage | |
|---|---|
| Internal drive bays | 8 |
| Hot-swap | Yes |
| Supported RAID controllers | 9350-8i |
| RAID levels | 0, 1, 10, JBOD |
| RAID support | Yes |
| Maximum storage capacity | 320 TB |
| Network | |
|---|---|
| LAN controller | Broadcom 57416 |
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet interface type | 10 Gigabit Ethernet |
| Ports & interfaces | |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| Serial ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 5 |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Design | |
|---|---|
| Redundant fans support | Yes |
| Product colour | Black |
| Chassis type | Tower |
| Performance | |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Performance management | XClarity Controller Platinum |
| Software | |
|---|---|
| Compatible operating systems | Microsoft Windows Server 2019Microsoft Windows Server 2022Red Hat Enterprise Linux 8.6Red Hat Enterprise Linux 8.7Red Hat Enterprise Linux 9.0Red Hat Enterprise Linux 9.1SUSE Linux Enterprise Server 15 SP4SUSE Linux Enterprise Server 15 Xen SP4Ubuntu 22.04 LTS 64-bitVMware ESXi 7.0 U3VMware ESXi 8.0 U1 |
| Operating system installed | No |
| Processor special features | |
|---|---|
| Intel Secure Key Technology version | 1.00 |
| Intel TSX-NI version | 0.00 |
| Intel Smart Response Technology version | 1.00 |
| Intel Stable Image Platform Program (SIPP) version | 0.00 |
| CPU configuration (max) | 1 |
| Power | |
|---|---|
| Number of redundant power supplies installed | 1 |
| Power supply | 1100 W |
| Redundant power supply (RPS) support | Yes |
| Operational conditions | |
|---|---|
| Operating altitude | 0 – 3050 m |
| Storage relative humidity (H-H) | 8 – 90% |
| Operating relative humidity (H-H) | 8 – 90% |
| Storage temperature (T-T) | -40 – 60 °C |
| Operating temperature (T-T) | 5 – 45 °C |
| General | |
|---|---|
| Product family | ThinkSystem |
| Weight & dimensions | |
|---|---|
| Weight | 39.1 kg |
| Depth | 734 mm |
| Height | 462 mm |
| Width | 175 mm |
