Lenovo 4XB7A13970 internal solid state drive 3.2 TB 2.5″ PCI Express 4.0 NVMe 3D TLC NAND
- 3.2 TB 2.5″ PCI Express 4.0
- 1000000 IOPS
- 390000 IOPS
- 3D TLC NAND NVMe
- Hardware encryption
- S.M.A.R.T. support
- Component for: Server/workstation
The ThinkSystem 7450 MAX Mixed Use NVMe SSDs are advanced data center SSDs optimized for mixed read-write performance, endurance, and strong data protection for Lenovo servers. With a PCIe 4.0 x4 interface, they are designed for greater performance and endurance in a cost-effective design, and to support a broader set of workloads. Now with SED encryption as standard, these drives help ensure data security, even when the drive is removed from the server.
The ThinkSystem 7450 MAX Mixed Use NVMe SSDs are advanced data center SSDs optimized for mixed read-write performance, endurance, and strong data protection for Lenovo servers. With a PCIe 4.0 x4 interface, they are designed for greater performance and endurance in a cost-effective design, and to support a broader set of workloads. Now with SED encryption as standard, these drives help ensure data security, even when the drive is removed from the server.
Lenovo Mixed Used SSDs like the 7450 MAX SSDs are suitable for mixed read-write and general-purpose data center workloads, however their NVMe PCIe interface means the drives also offer high performance. Overall, these SSDs provide outstanding IOPS/watt and cost/IOPS for enterprise solutions.
Self-encrypting drives (SEDs) provide benefits by encrypting data on-the-fly at the drive level with no performance impact, by providing instant secure erasure thereby making the data no longer readable, and by enabling auto-locking to secure active data if a drive is misplaced or stolen from a system while in use. These features are essential for many businesses, especially those storing customer data.
Features | |
---|---|
Certification | CE (Europe): EN55032, EN55024 Class B, RoHSFCC: CFR Title 47, Part 15, Class BUL/cUL: approval to UL-60950-1, 2nd Edition, IEC 60950-1:2005 (2nd Edition); EN 60950-1 (2006) + A11:2009+ A1:2010 + A12:2011 + A2:2013BSMI (Taiwan): approval to CNS 13438, Class B, CNS 15663RCM (Australia, New Zealand): AS/NZS CISPR32 Class BKC RRL (Korea): approval to KN32 Class B, KN 35 Class BW.E.E.E.: Compliance with EU WEEE directive 2012/19/EC.TUV (Germany): approval to IEC60950/EN60950VCCI (Japan): 2015-04 Class BIC (Canada): ICES-003 Class BMorocco: EN55032, EN55024 Class BUkrSEPRO (Ukraine): EN55032 Class B, IEC60950/EN60950, RoHS (Resolution 2017 No. 139)UKCA (UK): SI 2016/1091 Class B and SI 2012/3032 RoHS |
Mean time between failures (MTBF) | 2000000 h |
Hot-swap | Yes |
S.M.A.R.T. support | Yes |
Write latency | 15 µs |
Read latency | 80 µs |
Random write (4KB) | 390000 IOPS |
Random read (4KB) | 1000000 IOPS |
Hardware encryption | Yes |
Component for | Server/workstation |
Memory type | 3D TLC NAND |
NVMe | Yes |
Interface | PCI Express 4.0 |
SSD form factor | 2.5″ |
SSD capacity | 3.2 TB |
Weight & dimensions | |
---|---|
Weight | 70 g |
Height | 7 mm |
Depth | 100 mm |
Width | 70 mm |
Operational conditions | |
---|---|
Maximum operating altitude | 3050 m |
Non-operating shock | 1500 G |
Non-operating vibration | 20 G |
Operating relative humidity (H-H) | 5 – 95% |
Storage temperature (T-T) | -40 – 85 °C |
Operating temperature (T-T) | 0 – 70 °C |
