Kolink KL-500MV2 power supply unit 450 W 20+4 pin ATX ATX Black
- 80 Plus Bronze (230V EU) certified: minimum 88/85/85 percent efficiency at 50/100/20 percent load for reduced power consumption and heat
- Semi-modular design with flexible flat black cables. Easily detachable if not in use
- Silent design: embedded 120 mm fan with fine-tuned RPM curve and airflow improved air intake
- Advanced circuit design: DC to DC converters for +3.3V and +5V outputs for precise voltage regulation and best compatibility with the latest setups
- Best performance for high end systems & sufficient connectors
- Comprehensive protection functions: Over Voltage Protection (OVP), Under Voltage Protection (UVP), Short Circuit Protection (SCP) Over Current Protection (OC) and Over Power Protection (OPP)
Kolink Modular Power 500W 80 Plus Bronze Modular Power Supply
| Power |
| Power protection features |
Over current, Over power, Over voltage, Short circuit, Under voltage |
| Hold time |
16 ms |
| Efficiency |
87% |
| Max output current (+5Vsb) |
2.5 A |
| Max output current (-12V) |
0.3 A |
| Max output current (+5V) |
15 A |
| Max output current (+12V) |
37 A |
| Max output current (+3.3V) |
15 A |
| Combined power (+5Vsb) |
12.5 W |
| Combined power (-12V) |
3 W |
| Combined power (+5V) |
100 W |
| Combined power (+12V) |
444 W |
| Combined power (+3.3V) |
100 W |
| Power Factor Correction (PFC) type |
Active |
| Input current |
4 A |
| AC input frequency |
50 – 60 Hz |
| AC input voltage |
220 – 240 V |
| Peak power |
500 W |
| Total power |
450 W |
| Ports & interfaces |
| Cabling type |
Semi-Modular |
| PCI Express connector |
Yes |
| ATX power connector (20+4 pin) |
Yes |
| CPU power cable length |
60 cm |
| CPU power connector (4+4 pin) |
Yes |
| PCI Express power cable length |
60 cm |
| PCI Express power connectors (6+2 pin) |
2 |
| Peripheral (Molex) power cable length |
500,600 mm |
| Peripheral (Molex) power connectors (4-pin) |
2 |
| SATA power cable length |
500,600,700,800 mm |
| Number of SATA power connectors |
4 |
| Motherboard power cable length |
50 cm |
| Motherboard power connector |
20+4 pin ATX |
| Performance |
| Mean time between failures (MTBF) |
100000 h |
| ATX version |
2.31 |
| 80 PLUS certification |
80 PLUS Bronze |
| Power supply unit (PSU) form factor |
ATX |
| Purpose |
PC |
| Design |
| On/off switch |
Yes |
| Fan location |
Top |
| Number of fans |
1 fan(s) |
| Fan diameter |
12 cm |
| Cooling type |
Active |
| Product colour |
Black |
| Operational conditions |
| Operating temperature (T-T) |
0 – 40 °C |
| Safety regulation & standards |
| Safety |
ErP 2013 Lot 6, ErP 2014 Lot, EU 617/2013 |
| Certificates |
| Certification |
CB |
| Compliance certificates |
CE, RoHS |
| Weight & dimensions |
| Weight |
1.62 kg |
| Height |
86 mm |
| Depth |
160 mm |
| Width |
150 mm |
| Packaging data |
| Package type |
Box |
| Package weight |
1.72 kg |
| Package height |
95 mm |
| Package depth |
196 mm |
| Package width |
233 mm |
