Kingston Technology KSM26SES8/8MR memory module 8 GB DDR4 2666 MHz ECC
- 8 GB DDR4 2666 MHz
- 260-pin SO-DIMM
- CAS latency: 19
- 1.2 V
- ECC
Kingston’s KSM26SES8/8MR is a 1G x 72-bit (8GB) DDR4-2666 CL19 SDRAM (Synchronous DRAM) w/ parity, 1Rx8, ECC, memory module, based on nine 1G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-2666 timing of 19-19-19 at 1.2V. Each 260-pin SODIMM uses gold contact fingers.
| Features |
| JEDEC standard |
Yes |
| Backlight |
No |
| SPD profile |
Yes |
| Programming power voltage (VPP) |
2.5 V |
| Row active time |
32 ns |
| Refresh row cycle time |
350 ns |
| Row cycle time |
45.75 ns |
| Memory voltage |
1.2 V |
| Memory ranking |
1 |
| CAS latency |
19 |
| On-Die ECC |
Yes |
| ECC |
Yes |
| Memory form factor |
260-pin SO-DIMM |
| Memory clock speed |
2666 MHz |
| Internal memory type |
DDR4 |
| Internal memory |
8 GB |
| Buffered memory type |
Unregistered (unbuffered) |
| Operational conditions |
| Storage temperature (T-T) |
-55 – 100 °C |
| Operating temperature (T-T) |
0 – 85 °C |
| Technical details |
| Compliance certificates |
RoHS |
| Logistics data |
| Harmonized System (HS) code |
84733020 |
| Other features |
| Supported data transfer rates |
PC4-2666, PC4-2400, PC4-2133, PC4-1866, PC4-1600 |
