Intel Core i7-6950X processor 3 GHz 25 MB Smart Cache
- Intel® Core™ i7 X-series Extreme Edition i7-6950X 3 GHz
- 25 MB Smart Cache LGA 2011-v3
- Processor cores: 10 14 nm 64-bit 140 W
- Maximum internal memory supported by processor: 128 GB DDR4-SDRAM
The 6th generation Intel® Core™ i7 processors deliver a new class of computing with a host of new features to power the next generation of laptops and 2 in 1 PCs. Expect lighting fast speeds and peak performance through even the toughest of tasks and games. The built-in revolutionary Intel® Hyper-Threading Technology allows each processor core to work on two tasks at the same time for smoother multitasking while Intel® Iris™ graphics delivers stunning 3D visuals and faster, more advanced video and photo editing. Game the way you want and push the boundaries with overclocking for your most demanding gaming needs. The ultimate in peak performance.
Ready. Wake. Create.
From zero to power in a flash, the 6th generation Intel® Core™ processor wakes quicker than ever and lets you switch in and out of apps more seamlessly than ever.
Stunning Visual Experiences
With 6th generation Intel® Core™ processor Ultra HD graphics, your screen comes to life. Watch in a whole new way with 4k screens. Wireless displays let you create and game anywhere.
Security You Can Trust
Worry-free and hassle-free security is yours. With facial recognition and True Key™ technology, getting you logged in and protected has never been easier or more secure.
| Processor |
| Generation |
6th Generation |
| Processor ARK ID |
94456 |
| Processor code |
SR2PA |
| Processor codename |
Broadwell E |
| Thermal Design Power (TDP) |
140 W |
| Processor cache type |
Smart Cache |
| Processor cache |
25 MB |
| Processor boost frequency |
3.5 GHz |
| Processor operating modes |
64-bit |
| Processor threads |
20 |
| Component for |
PC |
| Cooler included |
No |
| Box |
No |
| Processor lithography |
14 nm |
| Processor socket |
LGA 2011-v3 |
| Processor cores |
10 |
| Processor base frequency |
3 GHz |
| Processor model |
i7-6950X |
| Processor generation |
6th gen Intel® Core™ i7 |
| Processor family |
Intel® Core™ i7 X-series Extreme Edition |
| Processor manufacturer |
Intel |
| Memory |
| ECC |
No |
| Memory channels |
Quad-channel |
| Memory clock speeds supported by processor |
2133,2400 MHz |
| Memory types supported by processor |
DDR4-SDRAM |
| Maximum internal memory supported by processor |
128 GB |
| Graphics |
| On-board graphics card |
No |
| Features |
| Commodity Classification Automated Tracking System (CCATS) |
G077159 |
| Export Control Classification Number (ECCN) |
5A992C |
| Scalability |
1S |
| Embedded options available |
No |
| PCI Express CEM revision |
3.0 |
| CPU configuration (max) |
1 |
| PCI Express slots version |
3.0 |
| Maximum number of PCI Express lanes |
40 |
| Market segment |
Desktop |
| Execute Disable Bit |
Yes |
| Idle States |
Yes |
| Processor special features |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel 64 |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel Smart Response Technology version |
1.00 |
| Intel Turbo Boost Max Technology 3.0 |
Yes |
| Intel Enhanced Halt State |
Yes |
| Intel® vPro™ Platform Eligibility |
No |
| Conflict-Free processor |
Yes |
| Intel® Turbo Boost Max Technology 3.0 frequency |
4 GHz |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Intel Trusted Execution Technology |
No |
| Intel® Smart Response Technology |
Yes |
| Enhanced Intel SpeedStep Technology |
Yes |
| General |
| Product family |
Core |
| Product series |
Extreme Edition |
| Technical details |
| Bus type units |
MHz |
| Intel Turbo Boost Max Technology frequency |
4000 MHz |
| Processor brand name |
Intel Core i7 X-seriesIntel Core i7 X-series processor |
| Last change |
63903513 |
| Product family |
Intel High End Desktop Processors |
| Launch date |
Q2’16 |
| Status |
Discontinued |
| Maximum memory |
128 GB |
| Processor cache |
25600 KB |
| Supported memory types |
DDR4-SDRAM |
| Product type |
Processor |
| Packaging data |
| Package type |
Retail box |
| Logistics data |
| Harmonized System (HS) code |
8542310001 |
| Other features |
| Maximum internal memory |
128 GB |
