DELL Xeon 5218 processor 2.3 GHz 22 MB
- Intel® Xeon® Gold 5218 2.3 GHz
- 22 MB LGA 3647 (Socket P)
- Processor cores: 16 14 nm 64-bit 125 W
- Maximum internal memory supported by processor: 1.02 TB DDR4-SDRAM
The Intel Xeon® 5218 2.3GHz Sixteen Core Processor enhances the performance and the speed of your system. Additionally, the Virtualization Technology enables migration of more environments. It supports enhanced SpeedStep® technology that allows tradeoffs to be made between performance and power consumption.
Its Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. The VT-x with Extended Page Tables (EPT) also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Packed with more features, the Xeon 5218 2.3GHz Sixteen Core Processor is the ideal choice for virtually all of your data demanding or standard enterprise infrastructure applications.
| Processor | |
|---|---|
| Processor ARK ID | 192444 |
| Processor codename | Cascade Lake |
| Thermal Design Power (TDP) | 125 W |
| Processor cache | 22 MB |
| Processor boost frequency | 3.9 GHz |
| Processor operating modes | 64-bit |
| Processor threads | 32 |
| Component for | Server/workstation |
| Cooler included | No |
| Box | No |
| Processor lithography | 14 nm |
| Processor socket | LGA 3647 (Socket P) |
| Processor cores | 16 |
| Processor base frequency | 2.3 GHz |
| Processor model | 5218 |
| Processor generation | 2nd Generation Intel® Xeon® Scalable |
| Processor family | Intel® Xeon® Gold |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| ECC | Yes |
| Memory channels | Hexa-channel |
| Memory clock speeds supported by processor | 2667 MHz |
| Memory types supported by processor | DDR4-SDRAM |
| Maximum internal memory supported by processor | 1.02 TB |
| Graphics | |
|---|---|
| Discrete graphics card model | Not available |
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Discrete graphics card | No |
| Features | |
|---|---|
| Scalability | 4S |
| Embedded options available | No |
| PCI Express CEM revision | 3.0 |
| Supported instruction sets | AVX-512 |
| PCI Express slots version | 3.0 |
| Maximum number of PCI Express lanes | 48 |
| Market segment | Server |
| Execute Disable Bit | Yes |
| Processor special features | |
|---|---|
| Intel Speed Select Technology (SST) | No |
| Intel® Optane™ DC Persistent Memory technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| AVX-512 Fused Multiply-Add (FMA) units | 1 |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® Resource Director Technology (Intel® RDT) | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Speed Select Technology – Base Frequency (Intel® SST-BF) | No |
| Intel TSX-NI | Yes |
| Intel Turbo Boost Max Technology 3.0 | No |
| Intel® Run Sure Technology | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Speed Shift Technology | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| General | |
|---|---|
| Product family | Xeon |
| Operational conditions | |
|---|---|
| Tcase | 87 °C |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85423119 |
| Technical details | |
|---|---|
| Launch date | Q2’19 |
| Status | Launched |
| Memory speed (max) | 2667 MHz |
| Number of UPI links | 2 |
| Product type | Processor |
| Weight & dimensions | |
|---|---|
| Processor package size | 76.0 x 56.5 mm |
| Other features | |
|---|---|
| Compatibility | – PowerEdge R640- PowerEdge R740- PowerEdge R940- PowerEdge R740XD- PowerEdge C6420- PowerEdge R440- PowerEdge T640- PowerEdge FC640- PowerEdge M640- PowerEdge M640 VRTX- PowerEdge R540- PowerEdge C4140- PowerEdge R840- PowerEdge R940xa- PowerEdge MX740C- PowerEdge MX840c- PowerEdge R740xd2- PowerEdge XR2 |
